Single Sensor
Single Sensor2x 1/8 in cooling water linesVacuum: MicrodotAtmosphere: BNC
Single Sensor
Single Sensor2x 3/16" cooling linesMicrodot connector
Dual sensor, shuttered
Dual sensor, shuttered2x 3/16" cooling lines1x 1/8" Air line2x microdot connectors
Dual Sensor with Shutter
Dual Sensor with Shutter2x 2x 1/8" cooling lines with 1/8" VCR fittings1x 1/8" air line with 1/8" VCR Fitting
Single Sensor with Shutter
Single Sensor with Shutter2x 1/8" cooling lines; 1/8" air line
Right Angle Sensor with 1/8 in. O.D. Cooling Tube
Right Angle Sensor with 1/8" O.D. Cooling Tubeslength 30"; crystal parallel to flange
Right Angle Sensor, front mounting
Right Angle Sensor, front mountingwith 3/16 in outer diameter cooling tubes
Single Sputter Sensor with Shutter
Single Sputter Sensor with ShutterSputtering head2x 1/4" cooling lines with mVCR1x 1/8" air lineMicrodot
Single Sensor Head, flat, compact, non-cooled
Single Sensor Head, flat, compact, non-cooled
Standard Single Sensor with Shutter
Standard Single Sensor with Shutter2 x ø 3/16 in cooling linesBNC-connector on atmosphere; microdot in vacuumlength flange-sensor: customer specified
UHV Single Sensor Head on CF40 (2 3/4 in)
UHV Single Sensor Head on CF40 (2 3/4 in)2x Fluid 3/16 in tube diameterBNC-connector on atmosphre and Microdot in vacuumincluding in-vacuum cable Microdot-MicrodotLength flange-sensor: customer specified
UHV Sensor Head on CF40 with Shutter
UHV Sensor Head on CF40 with Shutter2 x Fluid 3/16" dia.; 1x 3/16" airBNC-connector on atm; microdot in vacLength flange-sensor: customer specifiedincluding in-vacuum cable
Dual Sensor/Shutter, 1 in Bolt Feedthrough
Dual Sensor/Shutter 1" Bolt Feedthrough
Dual Sensor with shutter
Dual Sensor with shutter
UHV Dual Sensor Head on CF40 with Shutter
UHV Dual Sensor Head on CF40 with Shutter2 x Fluid 3/16" dia.;1x air 3/16"2x BNC-connector on atm; 2x microdot in vacLength flange-sensor: customer specifiedin-vacuum cable included
Right Angle Single Sensor on 1 in. feedthrough
Right Angle Single Sensor on 1" feedthrough2 x Fluid 3/16" dia.;BNC on atm; microdot in vacLength flange-sensor: customer specified
Right Angle Single Sensor on 2 3/4 in. CF
Right Angle Single Sensor on 2 3/4" CF2 x Fluid 3/16" dia.;BNC connector on atm; microdot in vacLength flange-sensor: customer specified
Single sensor with 1/8 in coiled tubes
Single sensor with 1/8 in coiled tubes2 x fluid 1/8 in diameter - coiledBNC-connector on atmosphere; microdot in vacuumLength flange-sensor: customer specified
Standard Single Sensor - KF40 Flange
Standard Single Sensor - KF40 Flange2 x Fluid 3/16 in.diameterlength (flange-sensor): customizedincluding in-vacuum cableconnection: BNC on atmosphere; Microdot in vacuum
Right Angle Single Sensor/NW-40 Flange
Right Angle Single Sensor/NW-40 Flange2x 3/16" fluid tubeBNC-connector on atmosphere; microdot in vacuumLength flange-sensor: customer specified
Right Angle Single Sensor/NW-50 Flange
Right Angle Single Sensor/NW-50 Flange2 x Fluid 3/16" dia.;BNC-connector on atm; microdot in vacLength flange-sensor: customer specified
Right Angle Single Sensor/NW-50 Flange
Right Angle Single Sensor/NW-50 Flange2 x Fluid 3/16" dia.;BNC-connector on atm; microdot in vacLength flange-sensor: customer specified
Bakeable Sensor Head on CF40, additional miniCF
Bakeable Sensor Head on CF40, additional miniCF2 x Fluid 3/16" dia.; 1x electrical 3/16"including embedded in-vacuum cable; bakeable up to 300 °Ccustomized length
