Magnetic Coupled Rotary Feedthrough, CF16, 180 deg
Hersteller unbekannt
| Quantity | Unit price |
|---|---|
| To 9 |
€840.00
|
| From 10 |
€645.00
|
Available in 56 days, delivery time 1-3 days
Product number:
BT-MR16R180S
Product information "Magnetic Coupled Rotary Feedthrough, CF16, 180 deg"
Magnetic Coupled Rotary Feedthrough, CF16, 180 degree, Pneumatic
Mounting Flange: NW16CF
Max. Bakeout Temperature: 150° (pneumatic actuator removed)
Output shaft diameter:φ6.35mm with M3 tapped hole
Adjustable angle rotation 0- 180°
Position sensors
Air pressure: 4-6 Bar
Torque @ 6 Bar: 0.14 Nm
Breakaway torque: 0.35 Nm
| Shaft diameter: | 4 - 10 mm |
|---|---|
| Water cooling: | No |
